CAT5E SFTP 24AWG 100MHz Purple PVC Jacket Shielded Lan Cable 500FT
Product Description:
The ITI LINK ITI CT5SF 027 CAT5E SFTP Cable delivers dependable network performance for a wide range of installations. Built with 24AWG solid oxygen-free copper conductors, this SFTP CAT5E cable combines foil and braided shielding to minimize EMI and RFI interference. Supporting up to 100MHz CAT5E bandwidth, it provides stable gigabit-speed data transfer for voice, video, and data communication.
Choose between PVC or LSZH jackets to suit your project needs—PVC offers flexibility and durability, while LSZH ensures low smoke and halogen-free safety in confined spaces. The 500FT bulk roll makes this cable ideal for structured cabling, LAN backbones, and industrial deployments.
Featuring a purple color-coded jacket for easy identification and compatible with standard RJ45 connectors, the ITI CT5SF 027 simplifies installation across data centers, 5G communication networks, security systems, and enterprise applications where signal integrity is critical.
Key Features
- High Performance CAT5E SFTP Design – Engineered with 24AWG solid copper conductors and dual shielding (foil + braid) for strong EMI/RFI protection, this SFTP CAT5E cable ensures stable 100MHz gigabit data transmission in high-interference environments.
- Durable LSZH/PVC Jacket Options – Choose between LSZH low-smoke halogen-free for safety-critical areas or PVC for flexible installation. Both jackets offer excellent resistance to wear, tear, and environmental stress.
- Reliable 500FT Length Roll – The 500FT bulk roll of CAT5E SFTP cable simplifies long-run installations, reducing connection points and signal loss for enterprise, industrial, or residential network setups.
- Wide Application Compatibility – Ideal for connecting computers, routers, switches, and patch panels. Perfect for LAN networks, data centers, 5G base stations, and security systems requiring high shielding performance.
- Easy Installation & Identification – Purple color-coded jacket allows quick recognition during complex wiring projects. Compatible with RJ45 connectors, this SFTP CAT5E cable provides easy termination and flexible deployment.
Technical Parameters:
| Product Description: CAT5E Shielded SFTP Cable 24AWG Durable Jacket 500FT |
| Rev.: A | ECN Description: |
| Construction Item Description | Electrical Property |
|
Conductor |
Material | Bare Solid Copper(elongation: 19 ~ 24%) | Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m |
| OD | 24 AWG | Resistance unbalance within a pair | ≤ 2% |
|
Insulation |
Material |
HDPE 8303 | Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V |
>1500 MΩ / 100m |
| OD | 0.90 ± 0.02 mm | Mutual capacitance | 5600 pF / 100m MAX |
| Average THK | 0.20 mm | Capacitance unbalance pair to ground at 800Hz or 1 kHz | ≤ 160 pF / 100m |
|
Color | 1p: white + 2 blue stripes & blue | Characteristic impedance at 100MHz | 100 ± 15 Ω |
| 2p: white + 2 orange stripes & orange | Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min |
No breakdown |
| 3p: white + 2 green stripes & green | Mechanical Property |
| 4p: white + 2 brown stripes & brown |
insulation | elongation before aging | ≥ 300% |
|
Pair Twist |
Lay & Direction | 1p: S=20.0 mm (28%) | tensile strength before aging | ≥12 MPa |
| 2p: S=17.5 mm (24%)) | elongation after aging | ≥ 150 % |
| 3p: S=22.0 mm (32%) | tensile strength after aging | ≥10.5 MPa |
| 4p: S=15.5 mm (21%) |
jacket | elongation before aging | ≥ 150 % |
| OD | / | tensile strength before aging | ≥ 13.5 MPa |
|
Inner Assemble | Lay | S=90 ± 5 mm | elongation after aging | ≥ 125 % |
| Direction | according to the drawing | tensile strength after aging | ≥ 12.5 MPa |
| Filler | / | Packing |
| OD | / | Drum | NA |
| Filler | Ripcord | 300D | Master Carton | NA |
| Drain Wire | Tinned Copper |
|
|
Outside Shield | Shield | Shield |
| Construction | / |
| Material | Polyester film/Aluminium Foil (PET/ALU) |
| Coverage | ≥ 115% |
|
Jacket | Material | PVC, 50P, -20~75℃ |
| Hardness | 81 ± 3 |
| OD | 6.5 ± 0.2 |
| Average THK | 0.50 ~ 0.60 |
|
Color | white |
| Marking Color | according to the customer's requirements |
| Marking | according to the customer's requirements |
Applications:
- LAN Networks: Perfect for connecting switches, routers, and PCs in office or campus networks using CAT5E SFTP for low-interference gigabit connectivity.
- Data Centers: Deploy in server racks and patch panels to ensure clean signal transmission in high-density environments.
- 5G and Industrial Networks: Reliable CAT5E SFTP connections for 5G base stations, manufacturing lines, and smart factory systems.
- Security and CCTV Systems: Use SFTP CAT5E cable to prevent signal noise in IP camera installations and control networks.
- Commercial and Residential Wiring: 500FT roll provides flexibility for home network setups and enterprise structured cabling projects.
